Double-Layer Space Frame Structure
Please provide your project location, building application, span requirements, roofing specifications, wind and snow load data, and local building codes.
Our engineering team will provide customized design, fabrication, packaging, transportation, and installation support services for your project.
Contact us today for a free structural proposal and budget quotation.
- Overview
- Recommended Products
Product Overview
A Double-Layer Space Frame Structure is a three-dimensional structural system consisting of top chords, bottom chords, and web members arranged into interconnected layers.
The upper and lower grids work together through diagonal web members to create a highly stable framework with excellent rigidity, load distribution, and structural efficiency.
Compared with single-layer roof systems, double-layer space frames offer greater strength, enhanced safety, and broader application flexibility, making them one of the most widely used solutions for large-span roofing projects worldwide.
Specifications & Parameters
| Category | Specifications / Parameters |
|---|---|
| Structure Type | Double-Layer Space Frame Structure |
| Grid Pattern | Square Pyramid, Reduced Square Pyramid, Triangular Pyramid, or Customized |
| Span Range | 20m – 120m+ (Customizable) |
| Covered Area | Customized per client requirements |
| Member Material | Q235B / Q355B Steel Tubes |
| Node Type | Bolted Ball Joints or Welded Ball Joints |
| Support Type | Perimeter Support, Point Support, or Multi-Point Support |
| Roofing System | Metal Roofing Panels, Aluminum-Magnesium-Manganese Roofing, or Skylight Panels |
| Surface Treatment | Painting, Hot-Dip Galvanizing, or Fluorocarbon Coating |
| Design Standards | In accordance with international and local building codes |
| Design Service Life | ≥ 50 Years |
Product Features
Excellent Structural Stability
Dual-layer configuration provides superior rigidity and safety.
Ideal for Long-Span Applications
Creates large column-free spaces with outstanding structural performance.
Efficient Load Distribution
Three-dimensional force transfer improves reliability and durability.
Cost-Effective Design
Optimized steel consumption reduces overall project costs.
Fast Installation
Prefabricated components enable efficient on-site assembly.
Compatible with Various Roofing Systems
Suitable for insulated roofs, skylight systems, and modern architectural envelopes.
Applications
•Urban Transportation Hubs
• International Logistics Centers
• Agricultural Trading Facilities
• Indoor Recreation Complexes
• Multi-Purpose Sports Centers
• Cold Chain Logistics Parks
• Modern Distribution Facilities
• Technology and Innovation Campuses
• Large Public Parking Structures
• Educational and Research Complexes
Frequently Asked Questions (FAQ)
Q: What is the difference between a double-layer space frame and a single-layer roof structure?
A: A double-layer space frame consists of two interconnected grids, providing higher rigidity and load-carrying capacity.
Q: What span range is suitable for this system?
A: It is commonly used for spans from 20 meters to over 120 meters, depending on project requirements.
Q: Can the structure be hot-dip galvanized?
A: Yes. Hot-dip galvanizing is available to improve corrosion resistance and service life.
Q: Is it suitable for heavy snow regions?
A: Yes. The structure can be engineered according to local snow load requirements.
Q: Do you offer customized structural solutions?
A: Absolutely. We provide tailored designs based on building function, span requirements, and architectural preferences.
Q: What is the warranty period?
A: 2 years.
Q: What are the payment terms?
A: FOB.
